X5's ballast is matched with Hella's ballast, and
X5's bulbs can be used on Hella's ballast without any cutting and using the
connecting jacks.
9000K Violet-White
H.I.D Conversion Kit can generally be installed into the car that uses
conventional halogen bulb headlight and has several advantages over halogen
bulbs:
More light output. A
35W HID light source produced up to 3 x the lumens at the light source when
compared to a 55W halogen bulbs.
Violet
white light. The color temperature of HID lighting more closely
approximates the color temperature of natural daylight than does a halogen
bulbs, which appears yellowish.
Greater visibility.
The combination of more light output and whiter color make for better visibility
in most night time driving conditions.
Longer Life. X5 HID
lamps will last, on the average over 5 times as long as halogen bulb.
Easy Conversion. HID
Conversion Kit is simple and easy to substitute for standard halogen bulbs.
Tests. Passed all of relevant environmental
tests including CE, e4, DOT(pending). Radiated and conducted emission meet CISPR
D/Class3, and Satisfy SAE and ECE
Mechanical Testing: Passed Thermal and Humidity Cycling, Vibration,
Shock, Water Jet, and Dust testing.
Design: HID conversion kit, X5 is design for retrofitting HID
headlamp system for the halogen housing
What is Xenon Light?
The xenon bulb is a micro-discharge bulb filled with a
mixture of noble gases including xenon. The bulb has no filament , as is the
case with a halogen bulb, but the light arc is created between two electrodes.
What was Xenon Light developed?
No less that 60% of all traffic accidents take place in
poorly lit conditions, Therefore, lighting greatly contributes to road safety an
comfort. It is a fact that the elderly required more light than the young (a
person aged 60 requires up to ten times more light than a twenty year-old)
What are the advantages of Xenon Light?
The xenon bulb provides more than twice the amount of
light of a halogen bulbs, while only consuming half the power (wattage). There
fore, the driver can see more clearly, and the car has more power for other
functions. Moreover, it is environmentally friendly, as less power means less
fuel consumption.
The clear white light produced by the xenon bulb is
similar to daylight. Research has shown that this enables drivers to concentrate
better. Furthermore, this particular light color reflects the road markings an
signs better that conventional lighting.
In practical terms, the life span of the bulb is equal to
that of the car, which means that bulbs need only be replaced in exceptional
cases.
Discovery
| |
Normal Halogen Bulb
|
HID Conversion Kit
|
| Wattage (W) |
50
|
35
|
| Lumens (Lm) |
1330
|
3600
|
| Life Expectancy |
350 hours
|
2000+ hours
|
| Efficiency (Lm/W) |
15
|
100
|
| Irradiation Color |
Lighter White
|
Violet Super White
|
| Color Temperature (K) |
2400
|
9000
|
Comparison
among the Ballasts
| |
Our X5 |
Osram |
Hella |
| Open circuit protection |
Intelligent ignition
(*1) |
50 times ignitions
(*2) |
4 times ignitions |
| Lamp socket short |
Protection |
- |
Protection |
| Aged lamp manipulation |
Protection |
No Protection
(*3) |
No Protection
(*4) |
| Production |
Yes |
No |
Yes |
| Molding |
Yes |
Yes |
No (*5) |
| Compatibility with
Korean Japanese lamps |
Excellent
(*6) |
Bad |
Good |
| EMI |
Excellent
(*7) |
Good |
Good |
*1 Our
Intelligent Ignition Strategy
Breakdown or empty socket: only 1
time ignition to protect operator and vehicle
Aged lamp: 3 times ignition
*2 Lots of ignitions
may cause the lamp life shortened
*3 Much aged lamp with more than 110V lamp voltage may not be lit because
of constant power control
*4 Though much aged lamp may be lit, the ballast
may get into overheat and permanent damage because of constant current control
*5 The ballast may not
be protected from the water
*6
We have tested its ballast's compatibility with OEM lamps (Philips, Osram, GE,
Matsushita) from 2001 and 6 Korean, Japanese lamps from Jan 2003.
*7 High Voltage cable
with shield is used Hella does
not use shield cable since noise filter is included in the D2 lamp socket. But
D2 lamp socket may be removed in the aftermarket. As a result of removing the
noise filter in the D2 socket, some abnormal symptoms may be appeared in the
vehicle.
EMI test result are available
Features:
-
No cutting and re-wiring required for entire installation.
-
35W. Xenon Gas Filled HID bulbs. No Filament
-
9000K color temperature. More light output
-
Highest quality
-
Longer life
-
Produce Super-White light and more intensity of lighting. Please see the
pictures how brilliant it is.
-
Easy to installation (20~40 minutes for a beginner)
-
CE Approved
One HID Kit contains everything you need
(no need to buy anything else):
-
HID 35W bulb. 2 bulbs. See Above
-
Ballast w/built-in ignitor 2pcs.
See Picture
-
Cable Tie 10pcs.
-
Bracket for Ballast. 2pcs.
-
3M foam adhesive. 6pcs.
-
Screws 8 pcs.
-
1 Spare Fuse (30A).
-
1 Installation Instructions.
|
Click to enlarge
|
|
